The ATOM28 from Yüzüak is an impact-type sprinkler with a robust metal housing, adjustable for full-circle or sector (part-circle) irrigation. The impact mechanism ensures uniform water distribution with a wide reach. With interchangeable nozzles; suitable for professional irrigation of fields, pastures, and sports fields, in both portable and fixed systems. The main body and the vane are made of aluminum with a lower rotation mechanism of brass, Teflon, and stainless steel, and thanks to the adjustable water breaker, the jet can be broken more or less as desired.
Features
- Usable nozzle-Ø: 10–14 mm
- Water consumption: 6.5–19 m³/h
- Throw distance: 18–26 m
- Jet angle: 30°
Technical data
| Nozzle Ø (mm) | Pressure (bar) | Throw distance (m) | Capacity (m³/h) | Irrigated area (m²) | Precipitation (mm/h) |
|---|---|---|---|---|---|
| 10 | 2 | 19 | 6.5 | 1134 | 5.7 |
| 10 | 3 | 21 | 7.8 | 1385 | 5.6 |
| 10 | 4 | 23 | 9.1 | 1661 | 5.5 |
| 10 | 5 | 23.5 | 10.5 | 1734 | 6.1 |
| 12 | 2 | 21.0 | 9.0 | 1385 | 6.5 |
| 12 | 3 | 23.0 | 11.2 | 1661 | 6.7 |
| 12 | 4 | 25.5 | 13.0 | 2042 | 6.4 |
| 12 | 5 | 26.5 | 14.2 | 2205 | 6.4 |
| 14 | 2 | 22.0 | 12.0 | 1520 | 7.9 |
| 14 | 3 | 23.5 | 14.1 | 1734 | 8.1 |
| 14 | 4 | 27.0 | 16.5 | 2289 | 7.2 |
| 14 | 5 | 28.0 | 18.8 | 2462 | 7.6 |
Performance values measured under ideal conditions; wind and other factors may affect them. Pressure measured at the nozzle.
